Tekin: 17.5 Gen4 Spec-R, 12.5mm Rotor Blue

  • Sale
  • Regular price $199.00
Tax included.
  • SKU : TT2762


  • Input Voltage: 1-2S LiPO - 25.5T / 21.5T / 17.5T / 13.5T / 10.5T / 6.5T

    Weight: 5.1oz / 145g

    Shaft Dimensions: 3.18mm (1/8") x 15.3mm

    Motor Diameter: 35.85mm / 1.40"

    Motor Length: 50.25mm / 1.978"
    Max Operating Temperature: 180°F / 82°C

    Max RPM: 100,000

    Bearing Dimensions: Front: 4x13x5mm

                                         Rear: 1/8x3/8x5/32"

    Rotor Size: 12.3mm BLACK - 25.5T
                        12.5mm BLUE - 21.5T / 17.5T / 13.5T / 10.5T

    Rebuildable: Yes
    Mounting Pattern: M3 @ 25.4mm / 1"

    OFF ROAD

     1:10 2WD Stock Buggy
     1:10 2WD Stock Truck
     1:10 2WD Stock Short Course
     1:10 4WD Stock Buggy

    ON ROAD

     1:12 2WD Pan Car
     1:10 2WD Pan Car
     1:10 World GT
     1:10 Formula 1
     1:10 4WD Stock Touring Car
     1:10 Drift

    OVAL

     1:10 2WD
     1:10 SK Car
     1:10 Stock Car
     1:10 Winged Sprint
     1S LiPo Classes

    Features

     60 Degrees Adjustable Timing Advance
     SPEC Racing Specific Design
     CNC Machined 6061-T6 Billet Aluminum Heat Sink Can
     Neodymium Sintered Magnet
     Precision Engineered for Maximum Energy Conversion
     High Purity Copper Windings Maximize Conductivity
     Low Resistance, High Power Solder Tabs
     Sensored System Ready
     Anodized End-bell Plates Maximize Corrosion and Wear Resistance
     High RPM Precision Bearings
     Oversized Front Bearing
     Rebuild-able Design
     Solder-less Sensor PCB Replacement
     Legal in Major Race Governing Bodies
     ROAR Approved

    OUR QUALITY PROMISE

    We guarantee our motors to be free from manufacturer defects for 180 days from date of purchase. All items are tested in a controlled environment prior to the packaging process to ensure you receive a top quality Tekin product. We strive to provide the highest grade professional components possible and we appreciate and treat every Tekin user as part of our family. We are RC enthusiasts designing and manufacturing quality products to give our fellow RC enthusiasts the best hobby experience possible.
