Operating speed:
7.4V-0.078sec/60°
8.4V-0.065sec/60°
Stall torque:
7.4V-38kg-cm(528oz-in)
8.4V-40kg-cm(556oz-in)
Gear Material:Stainless steel
Horn gear spline:25T Φ5.9
Size:40x20x36mm(1.57x0.79x1.42in)
Case Material:Full Metal
Weight:77g
Bearing:2BB
Motor type:Brushless
Operating Temperature:-15℃~+70℃
Operating travel :≈180±10°
Frequency:1520uS
Refresh Rate:333Hz
Pules width range :500-2500μsec
Dead band width:2μsec
Connector wire length:300mm
Waterproof level:IP67
Programmable:No
